The BARACUDA® Aquantis+™ is designed to ensure a better performing, more reliable and more efficient experience.
Equipped with a high-quality motor protected against overheating, this pump is engineered for long-term reliability. Premium, corrosion-resistant components ensure consistent performance.
Thanks to its refined shaft design, Aquantis+™ runs with minimal vibration and noise. Enjoy smoother operation and a more peaceful pool environment—ideal for residential settings where comfort matters.
Aquantis+™ is designed for convenience, featuring a large-capacity pre-filter that reduces cleaning frequency. The twist-and-lock lid allows quick, tool-free access, making routine servicing faster and easier.
| Models | 50M | 75M | 100M | 100T | 150M | 150T | 200M | 200T |
|---|---|---|---|---|---|---|---|---|
| SKU Codes | 77858 | 77859 | 77860 | 77861 | 77862 | 77863 | 77864 | 77865 |
| Voltage (V) | 230 | 230 | 230 | 230/400 | 230 | 230/400 | 230 | 230/400 |
| Frequency (Hz) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Power supply (phases) | 1 | 1 | 1 | 3 | 1 | 3 | 1 | 3 |
| Flow at Nominal Head (m³/h) | 7.0 | 13.0 | 16.5 | 17.0 | 19.5 | 20.0 | 22.5 | 23.0 |
| Nominal Head (m.c.w.) | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
| Max. Working Pressure (bars) | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 |
| Motor Rated Power (kW) | 0.37 | 0.55 | 0.75 | 0.75 | 1.10 | 1.10 | 1.50 | 1.50 |
| Max. Absorbed Power (kW) | 0.54 | 0.84 | 1.10 | 1.10 | 1.45 | 1.45 | 1.75 | 1.75 |
| Maximum Head (m.c.w.) | 13.0 | 15.0 | 17.0 | 17.0 | 20.0 | 20.0 | 25.0 | 25.0 |
| Maximum Flow rate (m³/h) | 16.0 | 21.0 | 23.0 | 23.0 | 25.0 | 25.0 | 27.0 | 27.0 |
| Max. Water Temperature (°C) | 35 | 35 | 35 | 35 | 35 | 35 | 35 | 35 |
| Max. Ambient Temperature (°C) | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 |
| Threaded ports (inches) | - | - | - | - | - | - | - | - |
| Pipe fittings (mm) | 50 | 50 | 50 | 50 | 50 or 63 | 50 or 63 | 63 | 63 |
| Pipe fittings (inches) | 1½" | 1½" | 1½" | 1½" | 1½" or 2" | 1½" or 2" | 2" | 2" |
| Prefilter Volume (liters) | 1.9 | 1.9 | 1.9 | 1.9 | 1.9 | 1.9 | 1.9 | 1.9 |
| Product Size A (mm) | 255.0 | 255.0 | 255.0 | 255.0 | 255.0 | 255.0 | 255.0 | 255.0 |
| Product Size H (mm) | 330.0 | 330.0 | 330.0 | 330.0 | 330.0 | 330.0 | 330.0 | 330.0 |
| Product Size L (mm) | 595.0 | 595.0 | 595.0 | 595.0 | 623.0 | 623.0 | 623.0 | 623.0 |
| Net weight (kg) | 9 | 11 | 12 | 16 | 18 | 18 | 18 | 18 |
| Packaging volume (m³) | 0.062 | 0.062 | 0.062 | 0.062 | 0.062 | 0.062 | 0.062 | 0.062 |
Aquantis+™ Single Speed Pump Information Leaflet
