The BARACUDA® Aquantis™ is a high-performance plastic self-priming pump that delivers high flow rates.
When you need dependable performance without overspending, this pump delivers. With Class F motor insulation and IPX5 protection, it’s built to handle everyday use with confidence.
Whether you’re upgrading an existing system or installing from scratch, this pump adapts easily. It comes in a range of power ratings and includes multiple inlet fitting options.
Built for small to medium-sized pools, this pump ensures steady flow circulation with minimal effort.
| Models | 30 | 35 | 40 | 50 | 75 | 100 | 150 | 200 |
|---|---|---|---|---|---|---|---|---|
| SKU Codes | 77802 | 77803 | 77804 | 77805 | 77806 | 77807 | 77808 | 77809 |
| Voltage (V) | 230 | 230 | 230 | 230 | 230 | 230 | 230 | 230 |
| Frequency (Hz) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Power supply (phases) | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Flow at Nominal Head (m³/h) | 4.1 | 5.8 | 8.9 | 11.2 | 12.5 | 15.0 | 19.7 | 22.5 |
| Nominal Head (m.c.w.) | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
| Max. Working Pressure (bars) | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 3.0 | 3.0 | 3.0 |
| Motor Rated Power (kW) | 0.24 | 0.24 | 0.42 | 0.50 | 0.60 | 0.75 | 1.10 | 1.60 |
| Max. Absorbed Power (kW) | 0.35 | 0.45 | 0.50 | 0.75 | 0.85 | 1.10 | 1.60 | 2.20 |
| Maximum Head (m.c.w.) | 11.0 | 12.0 | 12.0 | 12.5 | 12.5 | 16.0 | 18.0 | 19.5 |
| Maximum Flow rate (m³/h) | 9.5 | 11.0 | 14.0 | 15.5 | 16.5 | 22.5 | 28.0 | 31.0 |
| Max. Water Temperature (°C) | 35 | 35 | 35 | 35 | 35 | 35 | 35 | 35 |
| Max. Ambient Temperature (°C) | 40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 |
| Threaded ports (inches) | 1½" | 1½" | 1½" | 1½" | 1½" | - | - | - |
| Pipe fittings (mm) | 50 | 50 | 50 | 50 | 50 | 50 or 63 | 50 or 63 | 50 or 63 |
| Pipe fittings (inches) | 1½" | 1½" | 1½" | 1½" | 1½" | 1½" or 2" | 1½" or 2" | 1½" or 2" |
| Prefilter Volume (liters) | 0.80 | 0.70 | 0.90 | 1.00 | 0.70 | 1.20 | 1.20 | 2.20 |
| Product Size A (mm) | 180.0 | 180.0 | 180.0 | 180.0 | 180.0 | 220.0 | 220.0 | 220.0 |
| Product Size H (mm) | 188.5 | 188.5 | 188.5 | 188.5 | 188.0 | 256.0 | 256.0 | 256.0 |
| Product Size L (mm) | 374.0 | 374.0 | 405.0 | 405.0 | 405.0 | 518.0 | 548.0 | 548.0 |
| Net weight (kg) | 6.0 | 6.0 | 9.0 | 9.0 | 9.0 | 14.5 | 15.0 | 16.9 |
| Packaging volume (m³) | 0.014 | 0.014 | 0.015 | 0.015 | 0.015 | 0.033 | 0.035 | 0.036 |
Aquantis™ Single Speed Pump Information Leaflet
